Air Requirement

The largest electric motor available on single phase supply is normally 3 h.p. This will drive the pump of a l4 c.f.m. compressor, which will give l0 c.f.m. FAD (free Air Delivery). l0 c.f.m. FAD will sustain a constant 72 psi. through a nozzle 3mm. diameter. A compressor of l0 c.f.m. FAD would give the best results with both the ACE and the CLASSIC gritblasters at the higher pressures. Of course, smaller compressors (5 c.f.m. upwards) will also work, but will not sustain the higher pressure indefinitely. with a smaller compressor, you will either have to pause from time to time to allow the compressor to build up the pressure again, or let the gritblaster work continuously at the lower pressure (see chart below). the following chart gives an indication of the pressure you can expect your compressor to sustain when blasting continuously through the 3mm, 3.5mm & 2.5mm tungsten carbide nozzles

COMPRESSOR SIZE REQUIRED

*NOTE: this is where the top quality tungsten carbide pays dividends. Its low wear rate enables it to retain its bore diameter longer.

With cheaper nozzles (mild steel or ceramic) the high wear rate means your compressor cannot sustain its optimum working pressure. The larger nozzle bore means more air required

ACE Engineering Products, The Forge, Ousden, NEWMARKET, CB8 8TR U.K

.Tel. (+44) 01638 500255 Fax (+44) 01638 500255

logo

Back/ Next

Home Page THE CLASSIC THE ACE SODA BLASTING Air requirement FAQ MORE FAQPrices list gritblasters

Spares & accessoriesPrice list spares & accessoriesSafety EquipmentPrice list safety equipmentAce/Classic at workSend e-mail

Displacement
Free Air Delivered (FAD)
Pressure w/3mm nozzle
Pressure w/3.5mm nozzle
Pressure w/2.5mm nozzle
19 cfm (540L/min)
13 cfm (370L/min)
95 psi (6.5 bars)
72 psi (5 bars)
130 psi (9 bars)
(above max)
14 cfm (400L/min)
10cfm (300 L/min)
72 psi (5 bars)
55 psi (3.7 bars)
100 psi (7 bars)
10cfm (300L/min)
7 cfm (200L/min)
50 psi (3.5 bars)
40 psi (2.75 bars)
70 psi (5 bars)
8 cfm (225 L/min)
5 cfm (150 L/min)
36/5 psi (2.5 bars)
30 psi (2 bars)
50 psi (3.5 bars)
3.5 cfm (100 L/min)
2.5 cfm (70 L/min)
18 psi (1.25 bars)
15 psi (1 bar)
25 psi (1.7 bars)
